3NM Solar Marine Navigation Light

The product is a solar boat navigation light specially designed for the navigation safety of the non-powered boat such as Barge,Dredger or Tug boats.It complies with COLREGS(1972) and its visibility is up to 3NM.It has the characteristics of self-contained solar, durable ,anti-UV and easy-installation

Send Inquiry

Description

Technical Parameters

Features and Benefits:

Steady-on and its visibility: 3NM

Solar panel 1.5Wp, replaceable Ni-HM battery 4.8Ah.

Light Output : 112.5°Port/Starboard; 135°Stern.

Turns on at dusk and off at dawn automatically or by a touch switch.

Completely self-contained and waterproof IP67.

Charge under nearly all weather conditions and up to 100 hrs of operating capacity from a full charge.

Individual dome can protect the solar panel and raise its efficiency.

Lens is polycarbonate with anti-UV which is produced by Bayer.

Manufactured to ISO9001:2008 QAS and certified CE.

Specifications:

Light Output: Steady On

Average Intensity: white: 26cd; red: 24cd; amber: 20cd; green: 25cd

Visibility: 3NM

Horizontal Output: 112.5°， 135°，225°，360°

Minimum Autonomy: 100hrs

Latitude Range: 55°S to 55°N

On/Off Level: 60/100 Lux

Lifespan of LEDs: up to 100,000 hours

Solar panels: Mono-crvstalline Power 1.5Wp; Efficiency 16%

Battery: Ni-Mh, replaceable; 4.8A

Lens Material: Polycarbonate

Colored Lens Option: red, green, amber, white

Mounting Option: 4 bolts or Magnetic base

Weight: 0.9kg

Working Temperature Range: -40℃ to +80℃

Waterproof: IP67

Others Features:

Material: Plastic

LED Type: 33 x 0.2W LED

Color Temperature: white 4500K

Voltage: 10-24 VDC

Effective Lumen/Power compared to standard bulb:206Lumen/30W

Wattage: 2.5W

Visibility 3NM
